Foxconn G31MXP-K Lga 775 Motherboard
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Enlarge
Item Code:
MB4FOXG31MXPKV1
Manufacturer:
Model:
G31MXP-K
Item Description

Foxconn G31MXP-K Intel Socket LGA 775 Motherboard. Get excellent power of performance with Foxconn's G31MXP-K Motherboard. This micro-ATX motherboard is based around Intel's G31 and ICH7 chipsets and is ready to support the latest 45nm technology Intel LGA 775 socket Quad-core and Core 2 Duo processors as well as Pentium D and Celeron D CPUs with a front side bus of 1333 Mhz with 1600 Mhz speeds achievable through overclocking. A pair of 240-pin sockets allows you to install up to 4GB of DDR2 memory with dual channel support.

Features:

  • Intel Core 2 Quad, Core 2 Duo, Pentium Dual-Core, Pentium D, Pentium 4, Celeron processors, Socket T (LGA775)
  • Supports Intel 45nm Multi-Core processors
  • 1600(oc)/1333/1066/800/533 MHz (FSB)
  • Dual channel DDR2 800/667/533 x 2 DIMMs, Max 4GB
  • 1 x PCIe x16, 1x PCIe x1, 2 x PCI
  • ATA100 x 1 , SATAII x 4
  • 5.1 channel, Realtek ALC662
  • Gigabit Lan, Realtek RTL8111B/RTL8111D
  • 8 USB 2.0 ports

Specifications:

Processor:
Intel Core 2 Quad, Core 2 Duo, Pentium Dual-Core, Celeron Dual-core, Celeron processors, Socket T (LGA775), Supports Intel 45nm Multi-Core processors
Chipset:
Intel G31 + ICH7
Front Side Bus:
1600(oc) / 1333 / 1066 / 800 / 533 MHz (FSB)
Memory:
Dual channel DDR2 800/667/533 x 2 DIMMs, Max 4GB
VGA on Die:
Integrated
Expansion Slots:
1 x PCIe x16, 1 x PCIe x1, 2 x PCI
IDE:
ATA 100 x 1
Serial ATA(SATA)/RAID:
SATAII x 4
Audio:
5.1 channel, Realtek ALC662
LAN:
Gigabit Lan, Realtek RTL8111B/RTL8111D
Back Panel I/O Ports:
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x Serial port
1 x Parallel port
1 x Audio jack supports 3 jacks
1 x VGA port
4 x USB 2.0 ports
1 x RJ45 LAN port
Internal I/O Connectors:
1 x ATX 24-Pin power connector
1 x 4-Pin ATX 12V power connector
2 x 4-Pin CPU/System fan connectors
1 x CD-in connector
1 x Front Audio header
1 x ATA100 connector
1 x Floppy connector
1 x CIR header
1 x Front Panel connector
2 x USB 2.0 connectors support additional 4 ports
4 x SATAII connectors
1 x TPM header
1 x S/PDIF Out header
1 x Speaker header
1 x Intrusion Alarm header
BIOS Features:
8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Standards/Manageability:
PCI 2.3, USB2.0, DMI 2.5
Special Features:
FSB 1600 Achieved by overclocking
Form Factor:
Micro ATX (9.6” x 8.0”)


Click here for FoxconnG31MXP-K Latest Available Drivers




CPU Support List

CPU NameCoreCpu No.FSB (Mhz)L2 CacheWattage

Intel Celeron 1.60G

Conroe-L420800512KB35W

Intel Celeron 1.80G

Conroe-L430800512KB35W

Intel Celeron 2.00G

Conroe-L440800512KB35W

Intel Celeron 2.20G

Conroe-L450800512KB35W

Intel Celeron 2.2G

ConroeE1500800512KB65W

Intel Celeron 3.4G

Dual Core E32008001MB65W

Intel Celeron 2.5G

Dual Core E33008001MB65W

Intel Celeron 3.4G

TBDE39008001MB65W

Intel Celeron Dual-core 1.60G

ConroeE1200800512KB65W

Intel Celeron Dual-core 2.0G

ConroeE1400800512KB65W

Intel Celeron Dual-core 2.40G

ConroeE1600800512KB65W

Intel Celeron D 2.53G

Prescott326533256KB84W

Intel Celeron D 2.66G

Prescott331533256KB84W

Intel Celeron D 2.80G

Prescott336533256KB84W

Intel Celeron D 2.93G

Prescott341533256KB84W

Intel Celeron D 3.06G

Prescott345J533256KBNA

Intel Celeron D 3.06G

Prescott346533256KB84W

Intel Celeron D 3.06G

Cedar Mill347533512KB65W

Intel Celeron D 3.06G

Cedar Mill347533512KB86W

Intel Celeron D 3.20G

Prescott351533256KB84W

Intel Celeron D 3.20G

Cedar Mill352533512KB65W

Intel Celeron D 3.33G

Prescott355533256KB73W

Intel Celeron D 3.33G

Cedar Mill356533512KB65W

Intel Celeron D 3.46G

Cedar Mill360533512KB65W

Intel Celeron D 3.60G

Cedar Mill365533512KB65W

Intel Core 2 Extreme 2.93G

ConroeX680010664MB75W

Intel Core 2 Duo 1.80G

ConroeE43008002MB65W

Intel Core 2 Duo 2.00G

ConroeE44008002MB65W

Intel Core 2 Duo 2.20G

ConroeE45008002MB65W

Intel Core 2 Duo 2.40G

ConroeE46008002MB65W

Intel Core 2 Duo 2.60G

ConroeE47008002MB65W

Intel Core 2 Duo 1.86G

ConroeE630010662MB65W

Intel Core 2 Duo 1.86G

ConroeE632010664MB65W

Intel Core 2 Duo 2.13G

ConroeE640010662MB65W

Intel Core 2 Duo 2.13G

ConroeE642010664MB65W

Intel Core 2 Duo 2.33G

ConroeE654013334MB65W

Intel Core 2 Duo 2.33G

ConroeE655013334MB65W

Intel Core 2 Duo 2.40G

ConroeE660010664MB65W

Intel Core 2 Duo 2.66G

ConroeE670010664MB65W

Intel Core 2 Duo 2.66G

ConroeE675013334MB65W

Intel Core 2 Duo 3.00G

ConroeE685013334MB65W

Intel Core 2 Duo 2.53G

wolfdaleE720010663MB65W

Intel Core 2 Duo 2.66G

wolfdaleE730010663MB65W

Intel Core 2 Duo 2.8G

wolfdaleE740010663MB65W

Intel Core 2 Duo 2.93G

wolfdaleE750010663MB65W

Intel Core 2 Duo 3.06G

wolfdaleE760010663MB65W

Intel Core 2 Duo 2.66G

wolfdaleE819013333MB*265W

Intel Core 2 Duo 2.66G

wolfdaleE820013333MB*265W

Intel Core 2 Duo 2.83G

wolfdaleE830013333MB*265W

Intel Core 2 Duo 3.0G

wolfdaleE840013333MB*265W

Intel Core 2 Duo 3.16G

wolfdaleE850013333MB*265W

Intel Core 2 Duo 3.33G

wolfdaleE860013333MB*265W

Intel Core 2 QUAD 2.40G

KentsfieldQ660010664MB*2105W

Intel Core 2 QUAD 2.40G

KentsfieldQ660010664MB*295W

Intel Core 2 QUAD 2.66G

KentsfieldQ670010664MB*295W

IntelCore 2 QUAD 2.33G

YorkfieldQ820013334MB95W

Intel Core 2 QUAD 2.33G

YorkfieldQ8200S13334MB65W

Intel Core 2 QUAD 2.50G

YorkfieldQ830013334MB95W

Intel Core 2 QUAD 2.66G

YorkfieldQ840013334MB95W

Intel Core 2 QUAD 2.50G

YorkfieldQ930013336MB95W

Intel Core 2 QUAD 2.66G

YorkfieldQ940013336MB95W

Intel Core 2 QUAD 2.66G

YorkfieldQ9400S13336MB65W

Intel Core 2 QUAD 2.66G

YorkfieldQ9450133312MB95W

Intel Core 2 QUAD 2.83G

YorkfieldQ950013336MB95W

Intel Core 2 QUAD 2.83G

YorkfieldQ9550133312MB95W

Intel Core 2 QUAD 2.83G

YorkfieldQ9550S133312MB65W

Intel Core 2 QUAD 3.0G

YorkfieldQ9650133312MB95W

Intel Pentium Dual-core 1.60G

ConroeE21408001MB65W

Intel Pentium Dual-core 1.80G

ConroeE21608001MB65W

Intel Pentium Dual-core 2.00G

ConroeE21808001MB65W

Intel Pentium Dual-core 2.20G

ConroeE22008001MB65W

Intel Pentium Dual-core 2.40G

ConroeE22208001MB65W

Intel Pentium Dual-core 2.50G

wolfdaleE52008002MB65W

Intel Pentium Dual-core 2.60G

wolfdaleE53008002MB65W

Intel Pentium Dual-core 2.70G

wolfdaleE54008002MB65W

Intel Pentium Dual-core 2.8G

wolfdaleE630010662MB65W

Intel Pentium 4 2.80G

Prescott5115331MB84W

Intel Pentium 4 3.06G

Prescott5245331MB84W

Intel Pentium 4 3.00G

Cedar Mill6318002MB65W

Intel Pentium 4 3.20G

Prescott6408002MB86W

Intel Pentium 4 3.40G

Prescott6508002MB84W

Intel Pentium 4 3.40G

Cedar Mill6518002MB65W

Intel Pentium 4 3.60G

Cedar Mill6618002MB86W

Intel Pentium D 2.66G

Smithfield8055331MB*295W

Intel Pentium D 2.80G

Smithfield8208001MB*295W

Intel Pentium D 2.80G

Presler9158002MB*295W

Intel Pentium D 2.80G

Presler9208002MB*295W

Intel Pentium D 3.00G

Presler9258002MB*295W

Intel Pentium D 3.00G

Presler9308002MB*295W

Intel Pentium D 3.20G

Presler9358002MB*295W

Intel Pentium D 3.20G

Presler9408002MB*295W

Intel Pentium D 3.40G

Presler9458002MB*295W

Intel Pentium D 3.40G

Presler9508002MB*295W

Intel Pentium D 3.60G

Presler9608002MB*2NA
